products details

Created with Pixso. Home Created with Pixso. Products Created with Pixso.
Worm gear motor
Created with Pixso.

High Torque 12V/24V DC Worm Gear Motor Double Lead Screw 5840-31 Model Permanent Magnet Metal Drive Motor IP54 Explosion-proof

High Torque 12V/24V DC Worm Gear Motor Double Lead Screw 5840-31 Model Permanent Magnet Metal Drive Motor IP54 Explosion-proof

High Torque 12V/24V DC Worm Gear Motor Double Lead Screw 5840-31 Model Permanent Magnet Metal Drive Motor IP54 Explosion-proof

Brand Name: XINHEMOTOR
Model Number: 5840-31
MOQ: 2 pieces
Price: $6-11 / piece
Detail Information
Product Description
Detail Information
Place of Origin:
Guangdong, China
Certification:
ROHS
Continuous Current(A):
1.6A
Efficiency:
IE 2
Speed(RPM):
10~500RPM, Customized
Commutation:
Brush
Construction:
Permanent Magnet
Frame:
31mm
IP Rating:
IP54
Motor Mounting Type:
Flange Mount
Protect Feature:
Explosion-proof, Drip-proof
Rated Power:
15w
Speed Rpm:
100 RPM
Torque:
70KG.CM MAX, Customized
Type:
Gear Motor
Usage:
Boat, Car, Electric Bicycle, Home Appliance, Cosmetic Instrument, Smart Home, Boat, Car, Electric Bicycle, Fan, Home Appliance
Warranty:
3 Months ~ 1 Year
Keywords:
12/24 Volt Worm Gear Motor
Diameter:
31mm
Encoder:
With Or Without 48CPR
Voltage(V):
12VDC To 48VDC
Gear Types:
Metal Worm Gears
Product Description
High Torque 12V/24V DC Worm Gear Motor Double Lead Screw 5840-31 Model Permanent Magnet Metal Drive Motor IP54 Explosion-proof 0
Product Parameter
High Torque 12V/24V DC Worm Gear Motor Double Lead Screw 5840-31 Model Permanent Magnet Metal Drive Motor IP54 Explosion-proof 2
Model
Voltage
No load speed
Noload current
Stall torque
 Gear ratio

Unit: VDC
Unit: rpm
Unit: mA
Unit: kg.cm

5840-31-17
24V
470rpm
350mA
4.4 kg.cm
17:1
5840-31-100
24V
80 rpm
350mA
25 kg.cm
100:1
5840-31-200
24V
40 rpm
350mA
51 kg.cm
200:1
5840-31-670
24V
12 rpm
350mA
70 kg.cm
670:1
High Torque 12V/24V DC Worm Gear Motor Double Lead Screw 5840-31 Model Permanent Magnet Metal Drive Motor IP54 Explosion-proof 4
Product Name
Dc Worm Gear Drive Motor
Gear material
Stainless steel
Noise
Low Noise Level
Certification
CE/RoHS
Port Shipment
ShenZhen
Ship Date
5-7days
Other Questions
Welcome To Communicate With Us, If You Have Any Doubts, You Can Communicate With Us, We Will Answer Your Questions
Products Show
High Torque 12V/24V DC Worm Gear Motor Double Lead Screw 5840-31 Model Permanent Magnet Metal Drive Motor IP54 Explosion-proof 6
High Torque 12V/24V DC Worm Gear Motor Double Lead Screw 5840-31 Model Permanent Magnet Metal Drive Motor IP54 Explosion-proof 8
High Torque 12V/24V DC Worm Gear Motor Double Lead Screw 5840-31 Model Permanent Magnet Metal Drive Motor IP54 Explosion-proof 10
High Torque 12V/24V DC Worm Gear Motor Double Lead Screw 5840-31 Model Permanent Magnet Metal Drive Motor IP54 Explosion-proof 12
High Torque 12V/24V DC Worm Gear Motor Double Lead Screw 5840-31 Model Permanent Magnet Metal Drive Motor IP54 Explosion-proof 14
High Torque 12V/24V DC Worm Gear Motor Double Lead Screw 5840-31 Model Permanent Magnet Metal Drive Motor IP54 Explosion-proof 16
High Torque 12V/24V DC Worm Gear Motor Double Lead Screw 5840-31 Model Permanent Magnet Metal Drive Motor IP54 Explosion-proof 18
High Torque 12V/24V DC Worm Gear Motor Double Lead Screw 5840-31 Model Permanent Magnet Metal Drive Motor IP54 Explosion-proof 20
High Torque 12V/24V DC Worm Gear Motor Double Lead Screw 5840-31 Model Permanent Magnet Metal Drive Motor IP54 Explosion-proof 22
Related Products
High Torque 12V/24V DC Worm Gear Motor Double Lead Screw 5840-31 Model Permanent Magnet Metal Drive Motor IP54 Explosion-proof 24
High Torque 12V/24V DC Worm Gear Motor Double Lead Screw 5840-31 Model Permanent Magnet Metal Drive Motor IP54 Explosion-proof 26
High Torque 12V/24V DC Worm Gear Motor Double Lead Screw 5840-31 Model Permanent Magnet Metal Drive Motor IP54 Explosion-proof 28
Company Profile
High Torque 12V/24V DC Worm Gear Motor Double Lead Screw 5840-31 Model Permanent Magnet Metal Drive Motor IP54 Explosion-proof 30
Our company is located in the center of Shenzhen City. We are a specialized factory that produces ac/dc motor, gear motor, brushless motor, vacuum cleaner motor, stepper motor. Our products are applied to various kinds of devices, like kitchen appliances, air flow products, air conditioners, water heaters, water & induction pumps, power tools and electrical toys as well as household appliances.In line with the management idea of "humanist, the good faith is supreme" and the quality consciousness of "strives for perfection", we have gathered a team of specialists for engineering, manufacture, quality control, production management and technology development.Our company comprehensively complies with ISO9001:2001 management systems. We are supplying our motors to many famous worldwide companies of top brands with different applications in Europe, the Middle East, East Asia and South America.
High Torque 12V/24V DC Worm Gear Motor Double Lead Screw 5840-31 Model Permanent Magnet Metal Drive Motor IP54 Explosion-proof 32
High Torque 12V/24V DC Worm Gear Motor Double Lead Screw 5840-31 Model Permanent Magnet Metal Drive Motor IP54 Explosion-proof 34
High Torque 12V/24V DC Worm Gear Motor Double Lead Screw 5840-31 Model Permanent Magnet Metal Drive Motor IP54 Explosion-proof 36
High Torque 12V/24V DC Worm Gear Motor Double Lead Screw 5840-31 Model Permanent Magnet Metal Drive Motor IP54 Explosion-proof 38
Our Certification
High Torque 12V/24V DC Worm Gear Motor Double Lead Screw 5840-31 Model Permanent Magnet Metal Drive Motor IP54 Explosion-proof 40
Customer Praise
High Torque 12V/24V DC Worm Gear Motor Double Lead Screw 5840-31 Model Permanent Magnet Metal Drive Motor IP54 Explosion-proof 42
Packaging And Shipping
High Torque 12V/24V DC Worm Gear Motor Double Lead Screw 5840-31 Model Permanent Magnet Metal Drive Motor IP54 Explosion-proof 44
FAQ
High Torque 12V/24V DC Worm Gear Motor Double Lead Screw 5840-31 Model Permanent Magnet Metal Drive Motor IP54 Explosion-proof 46
1.Q: Are you trading company or manufacturer? A: We're manufacturer， We specialize in micro ac/dc motor and dc gear motor for more than 11 years. 2.Q: What is the payment term for a new customer? A: We can draw up an Ali Assurance Order Online for our new customer, which can pay online with Master Card, Visa, etc. 3. Q: what should I provide when I choose gearbox/speed reducer? A: 1) load condition 2) speed of rotation or speed ratio 3) work circumstance 4) space of installation 4.Q: Do you have a customized service for your standard motors? A: Yes, we can customize per your request for the voltage, speed, torque and shaft size/shape. 5.Q: What's your lead time? A: Generally speaking, our regular standard product will need 15-30days, a bit longer for customized products.
