| Brand Name: | XINHE MOTOR |
| Model Number: | D63R/L |
| MOQ: | 100 pieces |
| Price: | $25-28 / piece |
| Payment Terms: | T/T |
| Supply Ability: | 5000pcs/month |
| Motor Type | Voltage (V) | Power (W) | Speed (RPM) | Current (A) | Speed (RPM) | Current (A) | Torque (N.M) | Gear Ratio | Case Length |
|---|---|---|---|---|---|---|---|---|---|
| XH63L/R-1230-130 | 12 | 30 | 130±10 | ≤1.2 | 110±10 | ≤3.5 | ≥3.3 | 1:20 | 85 |
| XH63L/R-1230-150 | 12 | 03 | 150±10 | ≤1.2 | 150±10 | ≤4.5 | ≥4.5 | 1:20 | 85 |
| XH63L/R-2445-180 | 24 | 45 | 180±10 | ≤1.5 | 150±10 | ≤6.5 | ≥4.5 | 1:20 | 85 |
| XH63L/R-2445-150 | 24 | 45 | 150±10 | ≤1.2 | 130±10 | ≤4.5 | ≥3.3 | 1:20 | 85 |
| XH63L/R-4245-180 | 42 | 45 | 180±10 | ≤1.2 | 150±10 | ≤4.5 | ≥4.5 | 1:20 | 85 |
| XH63L/R-2445-210 | 24 | 45 | 210±10 | ≤1.2 | 180±10 | ≤6.5 | ≥5.0 | 1:20 | 85 |
| XH63L/R-4865-150 | 48 | 65 | 150±10 | ≤1.2 | 130±10 | ≤3.5 | ≥5.0 | 1:20 | 85 |
| XH63L/R-2480-65 | 24 | 80 | 65±5 | ≤1.4 | 60±10 | ≤4.5 | ≥6.0 | 1:60 | 85 |
| XH63L/R-2480-75 | 24 | 80 | 75±5 | ≤1.5 | 68±10 | ≤4.5 | ≥6.0 | 1:60 | 85 |
| XH63L/R-1280-80 | 12 | 80 | 80±5 | ≤1.8 | 68±10 | ≤9.0 | ≥6.0 | 1:60 | 85 |
| XH63W-22080-45 | 220 | 80 | 45±5 | ≤0.2 | 35±5 | ≤0.6 | ≥8.0 | 1:60 | 85 |
| XH63L/R-1245-170 | 12 | 45 | 170±10 | ≤1.4 | 150±10 | ≤10 | ≥3.5 | 1:24 | 85 |
| XH63L/R-2430-300 | 24 | 30 | 300±15 | ≤1.4 | 250±10 | ≤4.5 | ≥2.5 | 1:15 | 85 |
| XH63L/R-2430-30 | 24 | 30 | 30±3 | ≤1.0 | 235±3 | ≤3.5 | ≥4.0 | 1:75 | 85 |
