| Brand Name: | XINHE |
| Model Number: | XH-GM370-25D |
| MOQ: | 10 pieces |
| Price: | $4.65-6 / piece |
Model | Voltage | No load speed | Noload current | Stall torque | Gear ratio |
Unit: VDC | Unit: rpm | Unit: mA | Unit: kg.cm | ||
25D370H4 | 6V/12V | 2020 rpm | 550/275mA | 0.58 kg.cm | 4.4:1 |
25D370H9 | 6V/12V | 1010 rpm | 550/275mA | 1.25 kg.cm | 9.7:1 |
25D370H20 | 6V/12V | 480 rpm | 550/275mA | 2.6 kg.cm | 20.4:1 |
25D370H34 | 6V/12V | 285 rpm | 550/275mA | 4.3 kg.cm | 34:1 |
25D370H47 | 6V/12V | 210 rpm | 550/275mA | 5.8kg.cm | 47:1 |
25D370H75 | 6V/12V | 130 rpm | 550/275mA | 9.4 kg.cm | 75:1 |
25D370H99 | 6V/12V | 100rpm | 550/275mA | 11.5kg.cm | 99:1 |
25D370H172 | 6V/12V | 57rpm | 550/275mA | 18.8 kg.cm | 172:1 |
25D370H227 | 6V/12V | 43 rpm | 550/275mA | 24.8 kg.cm | 227:1 |
25D370H378 | 6V/12V | 26 rpm | 550/275mA | 30 kg.cm | 378:1 |
25D370H499 | 6V/12V | 19rpm | 550/275mA | 30kg.cm | 499:1 |
Product Name | 25mm 15rpm 24v best price high quality electric motor with gear box |
Gear material | Stainless steel |
Noise | Low Noise Level |
Certification | CE/RoHS |
Port Shipment | ShenZhen |
Ship Date | 5-7days |
Other Questions | Welcome To Communicate With Us, If You Have Any Doubts, You Can Communicate With Us, We Will Answer Your Questions |
