| Brand Name: | XINHE MOTOR |
| Model Number: | XH-GM370-25D |
| MOQ: | 100 pieces |
| Price: | $9.50-13 / piece |
Model | Voltage | No load speed | Noload current | Stall torque | Gear ratio |
Unit: VDC | Unit: rpm | Unit: mA | Unit: kg.cm | ||
37D3019-EN | 12V | 500rpm | 300mA | 6 kg.cm | 19:1 |
37D3030-EN | 12V | 350 rpm | 300mA | 8 kg.cm | 30:1 |
37D3050-EN | 12V | 200 rpm | 300mA | 12.3 kg.cm | 50:1 |
37D3067-EN | 12V | 150 rpm | 300mA | 14.5 kg.cm | 70:1 |
37D30100-EN | 12V | 100 rpm | 300mA | 16 kg.cm | 100:1 |
37D30131-EN | 12V | 80 rpm | 300mA | 18 kg.cm | 131:1 |
37D30168-EN | 12V | 62 rpm | 300mA | 23 kg.cm | 168:1 |
37D30270-EN | 12V | 35 rpm | 300mA | 70 kg.cm | 270:1 |
37D30506-EN | 12V | 21 rpm | 300mA | 70 kg.cm | 506:1 |
37D30810-EN | 12V | 13 rpm | 300mA | 70 kg.cm | 810:1 |
Product Name | Customized 12v Micro Dc Gear Motor Gearbox 25mm Gear Motor |
Gear material | Stainless steel |
Noise | Low Noise Level |
Certification | CE/RoHS |
Port Shipment | ShenZhen |
Ship Date | 5-7days |
Other Questions | Welcome To Communicate With Us, If You Have Any Doubts, You Can Communicate With Us, We Will Answer Your Questions |
