products details

Created with Pixso. Home Created with Pixso. Products Created with Pixso.
AC MOTOR
Created with Pixso.

220VAC/50/60HZ 1600W Compact 3-Stage 28Kpa High Efficiency IP50 Brushless DC Blower Motor Permanent Magnet Home Appliance

220VAC/50/60HZ 1600W Compact 3-Stage 28Kpa High Efficiency IP50 Brushless DC Blower Motor Permanent Magnet Home Appliance

220VAC/50/60HZ 1600W Compact 3-Stage 28Kpa High Efficiency IP50 Brushless DC Blower Motor Permanent Magnet Home Appliance

Brand Name: XINHE MOTOR
Model Number: XH-BL145
MOQ: 2 pieces
Price: $40-60 / piece
Detail Information
Product Description
Detail Information
Place of Origin:
Guangdong, China
Certification:
CE ROHS
Continuous Current(A):
10A
Efficiency:
IE 1
Speed(RPM):
35000rpm Max
Commutation:
Brushless
Construction:
Permanent Magnet
Frame:
145mm(5.71in)
IP Rating:
Ip50
Motor Mounting Type:
Flange Mount
Protect Feature:
Drip-proof
Rated Power:
1200w
Rated Voltage:
220vac
Speed Rpm:
35000rpm
Torque:
1N.m(0.74lb.ft)
Type:
Brushless Motor
Usage:
Boat, Car, Electric Bicycle, Fan, Home Appliance, Cosmetic Instrument, Smart Home
Warranty:
3 Months ~ 1 Year
Keywords:
BLDC BLOWER
Motor Model:
With Controller
Application:
Vacuum Cleaner
Motor Type:
Brushless Motor
Power:
1600w Max
Size:
Compact
Color:
Customer's Request
Feature:
High Efficiency
MOQ:
1 Piece/Pieces
Product Description
220VAC/50/60HZ 1600W Compact 3-Stage 28Kpa High Efficiency IP50 Brushless DC Blower Motor Permanent Magnet Home Appliance 0
220VAC/50/60HZ 1600W Compact 3-Stage 28Kpa High Efficiency IP50 Brushless DC Blower Motor Permanent Magnet Home Appliance 2
Product Description
220VAC/50/60HZ 1600W Compact 3-Stage 28Kpa High Efficiency IP50 Brushless DC Blower Motor Permanent Magnet Home Appliance 4
220VAC/50/60HZ 1600W Compact 3-Stage 28Kpa High Efficiency IP50 Brushless DC Blower Motor Permanent Magnet Home Appliance 6
220VAC/50/60HZ 1600W Compact 3-Stage 28Kpa High Efficiency IP50 Brushless DC Blower Motor Permanent Magnet Home Appliance 8
220VAC/50/60HZ 1600W Compact 3-Stage 28Kpa High Efficiency IP50 Brushless DC Blower Motor Permanent Magnet Home Appliance 10
220VAC/50/60HZ 1600W Compact 3-Stage 28Kpa High Efficiency IP50 Brushless DC Blower Motor Permanent Magnet Home Appliance 12
220VAC/50/60HZ 1600W Compact 3-Stage 28Kpa High Efficiency IP50 Brushless DC Blower Motor Permanent Magnet Home Appliance 14
220VAC/50/60HZ 1600W Compact 3-Stage 28Kpa High Efficiency IP50 Brushless DC Blower Motor Permanent Magnet Home Appliance 16
220VAC/50/60HZ 1600W Compact 3-Stage 28Kpa High Efficiency IP50 Brushless DC Blower Motor Permanent Magnet Home Appliance 18
Specification
item
value
Speed(RPM)
30000rpm
Continuous Current(A)
5A
Efficiency
IE 1
Warranty
3months-1year
Place of Origin
China
Brand Name
XINHE MOTOR
Model Number
XH-BL146
Use
BOAT, Car, Electric Bicycle, FAN, Home Appliance, Cosmetic instrument, SMART HOME
Type
BRUSHLESS MOTOR
Torque
1N.m
Construction
Permanent Magnet
Commutation
BrushLESS
Protect Feature
Drip-proof
Keywords
BLDC BLOWER
CONTROLLER type
CONTROLLER with PWM adjust speed
Application
Medical Equipment, vacuum cleaner
Motor type
AC DC Brushless Motor
POWER
1200w
Certification
CE ROHS
Size
Compact
Color
Customer's Request
Feature
High Efficiency
MOQ
1 Piece/Pieces
220VAC/50/60HZ 1600W Compact 3-Stage 28Kpa High Efficiency IP50 Brushless DC Blower Motor Permanent Magnet Home Appliance 20
220VAC/50/60HZ 1600W Compact 3-Stage 28Kpa High Efficiency IP50 Brushless DC Blower Motor Permanent Magnet Home Appliance 22
220VAC/50/60HZ 1600W Compact 3-Stage 28Kpa High Efficiency IP50 Brushless DC Blower Motor Permanent Magnet Home Appliance 24
220VAC/50/60HZ 1600W Compact 3-Stage 28Kpa High Efficiency IP50 Brushless DC Blower Motor Permanent Magnet Home Appliance 26
220VAC/50/60HZ 1600W Compact 3-Stage 28Kpa High Efficiency IP50 Brushless DC Blower Motor Permanent Magnet Home Appliance 28
220VAC/50/60HZ 1600W Compact 3-Stage 28Kpa High Efficiency IP50 Brushless DC Blower Motor Permanent Magnet Home Appliance 30
220VAC/50/60HZ 1600W Compact 3-Stage 28Kpa High Efficiency IP50 Brushless DC Blower Motor Permanent Magnet Home Appliance 32
220VAC/50/60HZ 1600W Compact 3-Stage 28Kpa High Efficiency IP50 Brushless DC Blower Motor Permanent Magnet Home Appliance 34
1.Q: Are you trading company or manufacturer? A: We're manufacturer， We specialize in micro ac/dc motor and dc gear motor for more than 11 years. 2.Q: What is the payment term for a new customer? A: We can draw up an Ali Assurance Order Online for our new
customer, which can pay online with Master Card, Visa, etc. 3. Q: what should I provide when I choose gearbox/speed reducer? A: 1)load condition 2) speed of rotation or speed ratio 3) work circumstance 4) space of installation 4.Q: Do you have a customized service for your standard motors? A: Yes, we can customize per your request for the voltage, speed, torque and shaft size/shape. 5.Q: What's your lead time? A: Generally speaking, our regular standard product will need 15-30days, a bit longer for customized products.
